IN6250LH-100

Intertecnica 6250 Right Hand 3 Point Fastener with Lock, to suit 92mm - 100mm Panel Thickness

Features:

• Easy-to-use lever action with adjustable strikes provides a positive seal by compressing the gasket along 3 points.
• For overlapping doors.
• European design & Styling
• Stainless Steel lever Handles
• Constructed from Industrial Grade Composited materials for strength and resistance from corrosion.
• Suitable for both negative & positive temperatures -40/40 °C
• Inside release handle with Photo luminescent arrows
• Invisible & Tamperproof fixings
• Soft & quiet operation
• Lockable
• No reinforcement is needed in the door leaf panel
• Includes luminous internal & external Arrow Labels.
• Max recommended door weight: 100kg
• Door height: 500mm - 3000mm
• Door width: 500mm - 2000mm
• Door panel thickness: 92mm - 100mm
• Door offset: 92mm - 140mm
• Left hand opening.

This Latch kit excludes the Connecting Rod between the latch and strikes. The manufacturer recommends that a Stainless Steel flat bar 20mm x 3mm thick is used.

Combine this latch set with Intertecnica's IN2830RV Hinge, which offers a non-lift-off hinge and tamper-proof fixings for added security.

CRH & All manufacturers highly recommend that all internal safety release mechanisms fitted to doors are checked at least 3 times weekly to ensure they are functioning correctly.
